3-way Wireless Light Switch Kit (Black)

Buy a kit and save!
Color Options:
White Black Light
Almond
Ivory Brown
Install a 3-way light switch without running any wire.
  • Control 1 load from 2 locations
  • Battery-free
  • Wireless
  • 868 MHz
  • 120V receiver
  • 100 ft. avg. range
Contents: (2) Decorator style switches [E8T-S1ABK-1]
(1) Built-in relay receiver [E8R-R12BP-1]
Manufacturer: EnOcean/ Ad Hoc Controls
Part Number: E8K-A21-BK
Price: $219.85

Description
Specifications
Description

The 3-way Switch Kit includes one RF receiver and two self-powered wireless light switches. The receiver is simply wired between the power and the light, then stored in the light box behind the fixture. The light switches are programmed to the receiver through a simple learning process. Mount the switches anywhere with industrial tape or screws.

Applications

Remodeling and Retro-fits
Self-powered wireless switches are the perfect solution whenever a new switch is needed at a hard to reach location. These switches save electricians and home owners time and hassle by eliminating the need for wires and switch boxes.

Other Applciations

  • Log Homes
  • ICF homes
  • SIP Homes
  • Commercial Remodeling
  • Any situation where running wires is a hassle

Specifications

Self-Powered Wireless Light Switch

Power Supply Self-generated
Frequency 868 MHz
Channel bandwith 280 kHz
Indoor range: 100 ft. avg.
Operating Temperature -13° F up to 149° F (-25° C up to 65° C)
Weight 5 oz.
Radio Certifications FCC (U.S.), IC (Canada)
For more detailed specifications see product datasheets (click here)


120V Receiver Specifications

Power Supply Input: 110-125VAC
Relay Output: 110-125VAC, 8.2A
Maximum Load (Incandescent lamp): 200W tungsten
Maximum Load (Fluorescent lamp): 140W ballast with cos=0.4-0.6
Maximum Load for other Devices: 1000W resistive (cos=1)
Number of Output Channels: 1
Indoor range: 100 ft. avg.
Dimensions: 4.7cm x 3.3cm x 2.8cm
(1.85in x 1.3in x 1.1in)

Weight: 5 oz.
Radio Certifications: FCC (United States)
Frequency: 868MHz
For more detailed specifications see product datasheets (click here)
